Vibratory Screening Machine

Product description

The rotary vibrating screen is a versatile and highly efficient screening machinery widely used in fields such as chemical engineering, food processing, and mining. It performs efficient classification, filtration, and impurity removal on powder, particles, and liquid materials through a unique three-dimensional vibration mode. The equipment adopts a fully enclosed structure, ensuring a clean production environment and preventing material leakage. It is compact in design, runs smoothly with low noise, and the screen mesh can be easily replaced. Moreover, it can flexibly adjust the screening process according to different material characteristics, achieving excellent precision and reliability to meet the stringent requirements of modern continuous production.

Working principle
The working principle of the rotary vibrating screen originates from its excitation source - the vertical vibration motor. At both ends of the motor, there is an adjustable eccentric weight. When the motor rotates at high speed, the eccentric weights generate strong centrifugal forces. These centrifugal forces are synthesized in the horizontal and vertical directions, ultimately driving the screen box and the screen mesh to produce a unique three-dimensional rotational vibration.
It is precisely this compound vibration that causes the materials on the sieve not to simply jump or slide, but to move along a complex spiral involute trajectory. Fine particles can quickly pass through the sieve and complete the separation, while coarse particles spiral along the sieve surface and eventually are automatically discharged from the discharge port, thus achieving efficient and continuous screening operations. The entire process is smooth and the screening is thorough.

Features & Benefits

1. Efficient prevention: Three-dimensional vibration effectively prevents screen blockage, significantly improving the accuracy and processing capacity of screening.
2. Multi-purpose: Easy adjustment, it can widely meet the screening needs of various materials such as dry, wet, coarse, fine and slurry.
3. Sealed and environmentally friendly: The fully enclosed design eliminates dust and liquid leakage, ensuring a clean production environment.
4. Economical and durable: Smooth operation and low consumption, convenient screen replacement and long lifespan, low maintenance cost.
5. Convenient integration: Compact structure, easy installation and cleaning, can seamlessly connect to automated production lines.

Product parameter

Production line diagram

1. Vacuum feeding into the mixer, automated, dust-free
2. The mixed materials directly enter the sieve machine for screening
